TUBI INDUSTRIALI

TUBI IN ACCIAIO INOSSIDABILE

TUBI INDUSTRIALI

TUBI INDUSTRIALI

TUBI TONDI*
DIAMETRO DA 8 A 34 mm	SPESSORE (mm)
	0.5	0.6	0.7	0.8	1.0	1.2	1.5	2.0
	PESI TEORICI kg/m
8	0.094	0.111	0.128	0.144	0.175	0.204	0.244
10	0.119	0.141	0.163	0.184	0.225	0.264	0.319
12	0.144	0.171	0.198	0.224	0.275	0.324	0.394
13	0.156	0.186	0.216	0.244	0.300	0.355	0.432
14	0.169	0.201	0.233	0.264	0.326	0.385	0.469
15	0.182	0.216	0.251	0.284	0.351	0.415	0.507
15.88	0.193	0.230	0.266	0.302	0.373	0.441	0.540
16	0.194	0.231	0.268	0.304	0.376	0.445	0.545
17.4	0.212	0.252	0.293	0.333	0.411	0.487	0.597
18	0.219	0.261	0.303	0.345	0.426	0.505	0.620
19	0.232	0.276	0.321	0.365	0.451	0.535	0.657	0.851
19.05	0.232	0.277	0.322	0.366	0.452	0.536	0.659	0.854
20	0.244	0.291	0.338	0.385	0.476	0.565	0.695	0.901
21.3	0.260	0.311	0.361	0.411	0.508	0.604	0.744	0.966
21.8	0.267	0.318	0.370	0.421	0.521	0.619	0.762	0.992
22	0.269	0.321	0.373	0.425	0.526	0.625	0.770	1.002
22.22	0.272	0.325	0.377	0.429	0.531	0.632	0.778	1.013
23	0.282	0.337	0.391	0.445	0.551	0.655	0.807	1.052
24	0.294	0.352	0.408	0.465	0.576	0.685	0.845	1.102
25	0.307	0.367	0.426	0.485	0.601	0.715	0.883	1.152
25.4	0.312	0.373	0.433	0.493	0.611	0.727	0.898	1.172
26.9	0.331	0.395	0.459	0.523	0.648	0.772	0.954	1.247
27	0.332	0.397	0.461	0.525	0.651	0.775	0.958	1.252
28	0.344	0.412	0.478	0.545	0.676	0.805	0.995	1.302
28.7	0.353	0.422	0.491	0.559	0.694	0.826	1.022	1.337
29	0.357	0.427	0.496	0.565	0.701	0.835	1.033	1.352
30	0.369	0.442	0.514	0.585	0.726	0.865	1.070	1.402
31.75	0.391	0.468	0.544	0.620	0.770	0.918	1.136	1.490
32	0.394	0.472	0.549	0.625	0.776	0.925	1.146	1.502
33	0.407	0.487	0.566	0.645	0.801	0.955	1.183	1.552
34	0.419	0.502	0.584	0.665	0.826	0.986	1.221	1.602

TUBI TONDI*
DIAMETRO DA 35 A 127 mm	SPESSORE (mm)
	0.5	0.6	0.7	0.8	1.0	1.2	1.5	2.0
	PESI TEORICI kg/m
35	0.432	0.517	0.601	0.685	0.851	1.016	1.258	1.653
38	0.469	0.562	0.654	0.745	0.926	1.106	1.371	1.803
38.1	0.471	0.563	0.656	0.747	0.929	1.109	1.375	1.808
39	0.482	0.577	0.671	0.765	0.951	1.136	1.408	1.853
40	0.495	0.592	0.689	0.785	0.977	1.166	1.446	1.903
42.4	0.525	0.628	0.731	0.833	1.037	1.238	1.536	2.023
43	0.532	0.637	0.741	0.845	1.052	1.256	1.559	2.053
44.4	0.550	0.658	0.766	0.873	1.087	1.298	1.611	2.123
44.45	0.550	0.659	0.767	0.874	1.088	1.300	1.613	2.126
45	0.557	0.667	0.776	0.885	1.102	1.316	1.634	2.153
48.3	0.598	0.717	0.834	0.951	1.184	1.415	1.758	2.319
50	0.620	0.742	0.864	0.986	1.227	1.466	1.822	2.404
50.8	0.630	0.754	0.878	1.002	1.247	1.490	1.852	2.444
51				1.006	1.252	1.496	1.859	2.454
52				1.026	1.277	1.526	1.897	2.504
53				1.046	1.302	1.556	1.934	2.554
54				1.066	1.327	1.586	1.972	2.604
55				1.086	1.352	1.616	2.009	2.654
60				1.186	1.477	1.767	2.197	2.904
60.3					1.485	1.776	2.208	2.919
63.5					1.565	1.872	2.329	3.080
65					1.602	1.917	2.385	3.155
70					1.728	2.067	2.573	3.405
75					1.853	2.217	2.761	3.656
76.1					1.880	2.250	2.802	3.711
80						2.368	2.948	3.906
88.9						2.635	3.283	4.352
101.6						3.017	3.760	4.988
114.3						3.398	4.237	5.624
120						3.569	4.451	5.909
127						3.780	4.714	6.260

Su richiesta sono disponibili anche spessori di 2,5 mm

* Classificazione austenitici

FINITURA SUPERIFICIE: finitura grezza
